| Place of Origin: | China |
|---|---|
| Brand Name: | xiangrui |
| Certification: | CE |
| Model Number: | TDL5Y |
| Minimum Order Quantity: | 1 set |
| Price: | negotiable |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, Western Union |
| Supply Ability: | 50 sets/month |
| Maximum Capacity: | 8x100ml | Temperature Setting Range: | Room Temperature ~ 80℃ |
|---|---|---|---|
| Temperature Control Accuracy: | ±2℃ | Heating Mode: | High-performance Heating Module |
| Net Weight: | 55kg | Maximum Speed: | 5000r/min |
| Maximum Relative Centrifugal Force: | 4390xg | Model: | TDL5Y |
| High Light: | Desktop Crude Oil Moisture Determination Centrifuge,Crude Oil Moisture Determination Centrifuge 5000r/Min |
||
TDL5Y Desktop Crude Oil Moisture Determination Centrifuge Maximum Speed 5000r/Min
Main technical performance
TDL5Y desktop crude oil moisture determination centrifuge is controlled by microcomputer and driven by AC variable frequency motor. It has stable operation and low noise. The whole machine noise is ≦58dB(A), and the speed accuracy is high, and the speed accuracy is ± 20r/min.
TDL5Y desktop crude oil moisture determination centrifuge has a touch panel and programmable operation. The host operating parameters can be set according to needs and automatically stored.
TDL5Y desktop crude oil moisture determination centrifuge has a large color screen display, humanized interface, and simple and convenient operation.
The TDL5Y desktop crude oil moisture determination centrifuge has real-time reading conversion and setting between rpm/RCF, which is convenient and fast.
The TDL5Y desktop crude oil moisture determination centrifuge is equipped with an electronic door lock and has multiple protection functions such as self-locking of the door cover, overspeed, overtemperature, imbalance, etc. It also has an automatic fault alarm function, which is safe and reliable.
The TDL5Y desktop crude oil moisture determination centrifuge has a 9-program rising/lowering rate curve, and the rising/lowering time can be set as needed.
TDL5Y desktop crude oil moisture determination centrifuge maximum speed 5000r/min.
The main technical parameters
| Model | TDL5Y |
| Maximum speed | 5000r/min |
| Maximum relative centrifugal force | 4390xg |
| Maximum capacity | 8x100ml |
| Speed accuracy | ± 20r/min |
| Time setting range | 1min~999min |
| Temperature setting range | room temperature ~ 80℃ |
| Application scope | refining laboratories, oil production workstations and petroleum research studios, etc. |
| Heating mode | High-performance heating module |
| Overall machine noise | ≦58dB(A) |
| Power supply | AC220V 50Hz 18A |
| Overall dimensions (LxWxH) | 590mmx660mmx420mm |
| Net weight | 55kg |
Application areas
The constant-temperature crude oil moisture determination centrifuge is a special centrifugal equipment used by the petroleum mining industry and scientific researchers to separate large-capacity petroleum moisture.
Adapt rotor parameters
| Rotor number | Rotor capacity | Maximum speed | Maximum relative centrifugal force |
| *** Horizontal rotor | 16×10/15ml | 4000r/min | 2860xg |
| NO.2 Horizontal rotor | 8×50/100ml | 4000r/min | 2980xg |
