| Place of Origin: | China |
|---|---|
| Brand Name: | xiangrui |
| Certification: | CE |
| Model Number: | TDL4-T |
| Minimum Order Quantity: | 1pc |
| Price: | negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Max RCF: | 6060xg | Maximum Capacity: | 4x750ml |
|---|---|---|---|
| Speed Accuracy: | ± 10r/min | Net Weight: | 115Kg |
| Temperature Setting Range: | -20～+40℃ | Power Supply: | AC220V 50Hz 15A |
| Overall Dimensions (LxWxH): | 730mmx650mmx390mm | Overall Machine Noise: | ≤58dB(A) |
| High Light: | Refrigerated Automatic Decapping Centrifuge,Low Temperature Automatic Decapping Centrifuge,Desktop Low Temperature Centrifuge |
||
TDL4-T Desktop Low Temperature Fully Automatic Decapping Centrifuge Refrigerated Type
Main technical performance
TDL4-T desktop low temperature fully automatic decapping centrifuge vacuum blood collection tube automatically decaps, the decapping success rate is 100%
The TDL4-T desktop low-temperature fully automatic decapping centrifuge is suitable for capping vacuum blood collection tubes in three lengths: 106/101/81mm.
The TDL4-T desktop low-temperature fully-automatic decapping centrifuge has a large screen and true color display, a humanized operation interface, and is simple and convenient to use.
The TDL4-T desktop low-temperature fully automatic decapping centrifuge has real-time reading conversion and setting between rpm/RCF, which is convenient and fast.
The TDL4-T desktop low-temperature fully automatic decapping centrifuge uses imported high-performance compressor fluorine-free refrigerant R404a, which meets environmental protection requirements and has good refrigeration effect.
The TDL4-T desktop low-temperature fully automatic decapping centrifuge adopts an electronic door lock, which is safe and reliable.
The TDL4-T desktop low-temperature fully-automatic decapping centrifuge adopts a special shock-absorbing structure with good shock-absorbing effect and has an automatic balancing function.
The TDL4-T desktop low-temperature fully automatic decapping centrifuge is equipped with multiple protection functions such as unbalance, overspeed, and door cover protection.
TDL4-T desktop low-temperature fully automatic decapping centrifuge has a maximum speed of 6000r/min and a maximum capacity of 4x750ml
The main technical parameters
| Model | TDL4-T |
| Maximum speed | 6000r/min |
| Maximum relative centrifugal force | 6060xg |
| Maximum capacity | 4x750ml |
| Speed accuracy | ± 10r/min |
| Time setting range | 1min~999min |
| Temperature setting range | -20～+40℃ |
| Temperature control accuracy | ±1℃ |
| Overall machine noise | ≤58dB(A) |
| Application areas | hospitals, blood stations, radioimmunoassay, nuclear medicine and other units |
| Overall dimensions (LxWxH) | 730mmx650mmx390mm |
| Net weight | 115Kg |
Adapted rotor parameters
| Rotor number | Rotor type | Rotor capacity | Maximum speed | Max RCF | Adapter can be added |
| 1 | horn rotor | 12x15ml | 6000r/min | 6060xg | 10/5ml |
| 2 | horizontal uncapping rotor | 48x5/3/2ml | 4000r/min | 3180xg | |
| 3 | horizontal uncapping rotor | 64x5/3/2ml | 4000r/min | 3190xg | |
| 4 | horizontal uncapping rotor | 80x5/3/2ml | 4000r/min | 3190xg | |
| 5 | horizontal uncapping rotor | 96x5/3/2ml | 4000r/min | 3360xg | |
| 6 | horizontal uncapping rotor | 4x750/500ml | 4000r/min | 3580xg | 250/100/50/10/5ml |
