| Place of Origin: | China |
|---|---|
| Brand Name: | xiangrui |
| Certification: | CE |
| Model Number: | TGL-20MC |
| Minimum Order Quantity: | 1 set |
| Price: | negotiable |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, Western Union |
| Supply Ability: | 50 sets/month |
| Maximum Speed: | 20500r/min | Maximum Relative Centrifugal Force: | 29860×g |
|---|---|---|---|
| Speed Accuracy: | ± 10r/min | Temperature Control Accuracy: | ±1℃ |
| High Light: | High Speed Tabletop Refrigerated Centrifuge,OEM Tabletop Refrigerated Centrifuge |
||
TGL-20MC Desktop High-Speed Refrigerated Centrifuge Temperature Control Accuracy ±1℃
Main technical performance
Microcomputer control, brushless DC motor drive, stable operation, low noise and high speed accuracy.
Touch panel, programmable operation, host operating parameters can be set according to needs and automatically stored.
TGL-20MC has a large-screen LCD display, and TGL-20M has a digital display, humanized interface, and easy and convenient operation.
Real-time reading conversion and setting between rpm/RCF, convenient and fast.
Equipped with an electronic door lock, it has various protection functions such as door cover self-locking, overspeed, overtemperature, etc.; it also has an automatic fault alarm function, which is safe and reliable.
It has 20 programs of increase/decrease rate curve, and the increase/decrease time can be set as needed.
The main technical parameters
| Model | TGL-20MC |
| Maximum speed | 20500r/min |
| Maximum capacity | 6x100ml |
| Time setting range | 1min~999min |
| Temperature setting range | -20～+40℃ |
| Compressor unit | imported high-performance compressor unit, environmentally friendly refrigerant R404a |
| Application areas | clinical medicine, biochemistry, genetic engineering, and immunology. |
| Overall machine noise | <58dB(A) |
| Power supply | AC220V 50Hz 10A |
| Overall dimensions (LxWxH) | 630mm×424mm×340mm (L×W×H) |
| Net weight | 68kg |
Adapt rotor parameters
| Rotor number | Rotor name | Capacity (number of tubes × ml) | Maximum rotation speed (r/min) | Maximum centrifugal force × g | Adapter can be added |
| NO.01 | Angle rotor | 12×1.5/2.2ml | 18500 | 23800 | 0.2-0.5ml |
| NO.02 | Angle rotor | 8/10/12×5ml | 15000 | 16600 | 0.2-0.5ml/1.5ml |
| NO.03 | Angle rotor | 4×(8×0.2ml) | 14000 | 13590 | PCR8*0.2ml test tube |
| NO.04 | Angle rotor | 24×1.5/2.2ml | 15000 | 21890 | |
| NO.05 | Angle rotor | 30×1.5/2.2ml | 13000 | 17950 | |
| NO.06 | Angle rotor | 36×1.5/2.2ml | 13000 | 15490 | |
| NO.07 | Angle rotor | 48×0.5ml | 16000 | 23669 | |
| NO.08 | Angle rotor | 48×1.5/2.2ml | 13000 | 17570 | |
| NO.09 | Angle rotor | 12×10ml | 13000 | 16240 | |
| NO.10 | Angle rotor | 8/10×15ml | 13000 | 17960 | |
| NO.11 | Angle rotor | 8/10×15ml ( Z ) | 12000 | 15290 | Z ―― Sharp bottom |
| NO.12 | Angle rotor | 6×50ml | 12000 | 14650 | Can be equipped with 10ml adapter |
| NO.13 | Angle rotor | 4×100ml | 11000 | 13200 | |
| NO.14 | Angle rotor | 6×50ml ( Z ) | 11000 | 13120 | Z ―― Sharp bottom |
| NO.15 | Angle rotor | 12×15ml | 11000 | 13520 | |
| NO.16 | Mildew standard rotor | 2×2/4×96 holes | 4000 | 2300 |
